Hi-lift Jacks are essential pieces of kit for off roading and recovery.
Hi-lift jacks are designed to help you survive in the most demanding situations – whether you are in the Moab desert canyons, the Welsh Mountains, the Amazon jungle, or the farmlands of Indiana. With a full-range of specially designed accessories, the Hi-Lift jack is just about the most versatile piece of off-roading/farm/auto recovery equipment you can buy. When it’s a heavy-duty situation, the tool had better be a Hi-Lift!
Hi-Lift Jack Specifications
- Approximate weight: 30lbs (14 kg)
- 4,660 lbs (2113.74 kg) rated capacity
- Tested capacity 7,000 lbs.
- Climbing pins of specially processed steel with 125,000 PSI tensile strength and 100,000 PSI yield.
- Steel bar is manufactured of specially rolled extra high carbon steel with 80,000 pound minimum tensile & carbon .69 to .82.
- Steel handle of 14gauge high-yield structural tubing with minimum yield of 55,000 PSI. 1 5/16″ diameter x 30″ long.
Hi-Lift Jack Features
- Every Jack comes complete with an adjustable top clamp/clevis for use in clamping and winching.
- Safety bolt is designed to shear at 7,000 lbs. (3175 kg)
- For speedy disengaging, lifting unit automatically drops away when load is removed.
- 4 1/2″ (11cm) long lifting nose for positive contact with load.
- Steel bar can be reversed for extra long life.
- Low pickup of 4 1/2″ (11cm).
- 28 square inch base plate.
